Cantilever Dugouts
- Attractive shelter without visual obstruction
- Fully preassembled powder coated steel roof and columns
- Roof, fascia and columns offered in various colors and rear offset differences; 8″ or 24″
- Industry exclusive 5-year manfacturer’s product warranty
- Custom sizes and designs available upon request
DESCRIPTION
Prefabricated baseball and softball cantilever dugouts that are an affordable dugout that is both attractive and functional. This dugout design provides your team a shelter from the sun and other elements during a game or practice. Our dugouts are available in a wide variety of widths and lengths. Custom lengths available upon request.
These cantilever dugouts are preassembled structures are manufactured from sturdy powder coated steel support beams and an angled corrugated metal roof. The plate mounted design eliminates the need for expensive concrete footings. The dugouts are manufactured with a durable powder coated steel frame and available in a variety of standard colors.
Finish your modular dugout upgrade by adding our aluminum or polyboard team benches to your athletic venue.
CHOOSE YOUR CANTILEVER DUGOUT COLORS
DOCUMENTATION
CD - Cantilever Dugout
| Title | Size | Date added | Download |
|---|---|---|---|
| Cantilever Dugouts - 24 Rear Offset | 708.09 KB | 20-09-2023 | Download |
| Cantilever Dugouts - 8 Rear Offset | 606.73 KB | 20-09-2023 | Download |
| Cantilever Dugout | 1.31 MB | 20-09-2023 | Download |
| Cantilever Dugout | 314.86 KB | 20-09-2023 | Download |
| CDO Installation Guideline 10262016 | 2.21 MB | 20-09-2023 | Download |
| CD10X48O24 - Cantilever Dugout 10'W x 48'L 3-Part Specification | 59.50 KB | 20-09-2023 | Download |
| CD10X48O8 - Cantilever Dugout 10'W x 48'L 3-Part Specification | 59.50 KB | 20-09-2023 | Download |
| CD10X40O24 - Cantilever Dugout 10'W x 40'L 3-Part Specification | 59.50 KB | 20-09-2023 | Download |
| CD10X40O8 - Cantilever Dugout 10'W x 40'L 3-Part Specification | 59.50 KB | 20-09-2023 | Download |
| CD10X32O24 - Cantilever Dugout 10'W x 32'L 3-Part Specification | 59.50 KB | 20-09-2023 | Download |
PESDO - Stamped drawings and calculations by a licensed professional engineer
